Aansluiting: G 1/8

Size 0

Housing die-cast zinc, painted silver

Min. medium temperature -10 °C

Max. medium temperature 60 °C

Min. ambient temperature -10 °C

Max. ambient temperature 60 °C

Flow rate 800 l/min

Condensate drain semi-automatic

DN 5

Filter rating 8 µm

Max. input pressure 16 bar

Bowl Polycarbonate container

A 40.0 mm

B 112.0 mm

C 10.0 mm

D 102.0 mm

Series Standard-mini

Flow rate measurement at P2 = 6 bar and pressure drop Δp = 1 bar

Country of origin DE

Customs tariff number 84213925

REACH SVHC1 substance name no

CAS no. SVHC 1 7439-92-1

RoHS materials notice Rohs compliant

REACH Info no SVHC substance included

Class name EASY

Sealant NBR
